January 27, 2017

Windlass Installation Details

This post is a detailed supplement to our post about installing our new windlass. [Read that one first...]

Following is a storyboard of photos [with detailed annotations] demonstrating and describing the retrofitting of a new Lighthouse windlass on Denali Rose's foredeck.

Original Nico Marine windlass (ç 1983) and 3/8" BBB chain.

The green tape is what I used for marking the layout of the new windlass. [Note: Starboard chain is not in its gypsy in this shot; it is temporarily draped over the clutch wheel so it is out of the way for measuring.]



Laying out new windlass.

Note: the anchor locker divider (3/4" marine plywood-resin coated) is intensionally off-set slightly to port. [i.e., The starboard locker is larger and so will be used for main bower...]

Triangular top [deck] plate is in the lower left of this field drawing, and is shapped to match the existing raised section on deck. The rectangular backing plate is on upper half of drawing.

Out with the old... and reconfirm layout...


Dry fitting new deck plate; marking bolt holes for drilling. The yellow canister is the windlass motor encased in a kevlar wrap with a molded urethane base that has a removable bottom to accommodate water tight wire penetrations.



Swiss cheese deck from old and new windlass holes. This is why I had the custom deck plate and large backing plate fabricated. [Both are 1/4" thick 316 stainless steel and will be bonded with 3M 4200UV- VS. 5200- to accommodate future removal if necessary...]

Note: Nauticat does not use any coring in their hand layed-up fiberglass hulls- including the deck. The deck was just shy of 1 inch thick were these holes are.


Backing plate placed on top of deck plate [for reference] to demonstrate layout and coverage...

The backing plate lower right corner [in photo] is notched because I didn't have time to remove the old foot switch which has a ~2 hole through the deck. This hole will become a small, clear deck plate for viewing the propane A-B switch in the future.

In retrospect, I wish I had removed the rectangular grey cover securing a since abandoned 12 VDC outlet, and extended the SS deck plate over that hole as well...

Also note the 2 inch ID tubes welded to the backing plate where the two chains lead through  [i.e., hawseholes...] Those tubes are long enough [1 inch to match deck thickness- per my request] to mate with the SS deck plate [protecting the non-cored deck from the anchor chain] and extend another 2 inches into the anchor well. These are for clamping 2 inch ID exhaust tubing to for leading the chain in the chain locker [and quieting any rattling...]



Boat bling. New 1501 Windlass from Lighthouse manufacturing. [Dry fitting after drilling holes through deck...]


A view of the permanent install (looking aft .) You can just make out the yellow drive motor, below. (The loose wiring is for the propane solenoid and was later attached to the underside of the deck.)

The perforated rubber floor matts in the background are remnants from lining the bottom [2 layers on the bottom...] and all sides [single layer] of the anchor locker to prevent the chain from making direct contact. This prevents unnecessary wear on the hull, quiets the chain in the locker, and allows for water to drain and the chain to dry.

In this view you can [barely] see I had to notch the 3/4" plywood anchor locker divider to allow clearance for the motor. Also note the forward most 1/2" hex bolts on the windlass base. These mate to nuts welded to the backing plate, greatly simplifying installation.

The finished installation. This view also shows the captive, tight fitting slotted stainless hawsehole covers/chain retainers. These fit tightly over the rectangular polyurethane boot which is an extension of the cast polyurethane base which negates the need for any sealant- making future removal of the windlass a simple matter of removing 6 bolts and dropping the motor.

The deck and backing plates were bedded using 3M 4200UV so they could be removed in the future if necessary.

Preparing to pull [from a full barrel; 550 feet] of 5/16 inch grade 43 chain into the starboard locker [for the first time] to see how much will free-fall. [Ultimately this was done on both sides of the divided anchor locker...]

This is the 'middle' of the 550' length [1 barrel] of 5/16" grade 43 chain after both ends were pulled into their respective chain lockers. It was cut here and attached to the two anchors. [360' for the main bower on starboard; 190 feet for the secondary bower on port.] Both sides have rope rodes attached to the chain.  See our Ground Tackle Inventory page for specific details.


After shot of windlass and anchors in 2014  (60# CQR on port; 80# Supermax as main bower on stbd.) [We later changed our groundtackle configuration...]


Note the 1/2" 'Starboard' installed on foredeck and anchor locker lids to protect fiberglass deck from anchors, chain, etc.




For those who desire even more information, here are the complete details about our groundtackle system.
